| Chassis Model | QL5330TZZU1VDZY | ||
| Chassis Parameters | Chassis Dimension(Lx WxH): | I1600x2540x 3706(mm) | |
| Curb Weight: | 14400Kg | ||
| GVW; | 33000Kg | ||
| Wheelbase: | 5820+1370mm | ||
| Drive Type: | 6×4 | ||
| Engine | Engine Model: | 6UZ1-TCG50, EURO5 | |
| Engine Power: | 279Kw | ||
| Displacement: | 98.39ml | ||
| Horsepower: | 380Ps | ||
| Transmission | Transmission: | ZF8S2030TO | |
| Forward Gear: | 8 Speed Gear | ||
| Backward Gear: | 2 Speed Gear | ||
| Seats | Front Seat: | 2 | |
| Cabin | ISUZU GIGA, one sleeper | ||
| Chassis | Front /Rear wheel distance: | 2065, 1855/1855mm | |
| Front/Rear overhang | 1 370/2590mm | ||
| Axle Loads: | 7000/26000kg | ||
| Approach/Departure Angle: | 17/18″ | ||
| Leaf Spring: | 8/10 | ||
| Rear Axle Ratio: | 4.555 | ||
| Tire Model: | 315/80R22.5,11pc | ||
| Standard Configuration | Power steering system, Air Conditioning, Tubeless Tire, ABS, Free Maintenance Battery, Central Lock, Power Window, Driving Data recorder. Front Chrome Kit Aluminum alloy air reservoir, remote key | ||
| Upper Body specs | |||
| Tank volume | Carbon steel, 31.1CUBIC | ||
| Tank body length | 8750mm | ||
| Compartments | 4 | ||
| Up and down Auger length | 9000mm | ||
| Driven method | External power supply | ||
| Auger motor | ABB | ||
| Voltage | 220V, three-phase, 60HZ | ||
