| Item | Specification |
|---|---|
| Molding power | Hydraulic |
| Molding R arc | 25, 35, 300 (made on request) |
| Maximum wing thickness × width | 22 × 170 mm |
| Hydraulic system pressure | 31.5 MPa |
| Overall power | 11 kW |
Wing Molding Machine
Applied to longitudinal beam pressing of upper and lower wing stringers.
By using hydraulically driven molds, the wing bending process is performed in a vertical position, allowing operation without turning the wing.
The equipment can perform turning, pressing, and R-arc bending according to customer requirements.
The equipment consists of a horizontal press, press molds, hydraulic systems, fuel tanks, and an electrical control system.
