| Vehicle Parameters | Vehicle Model: | QL1180XMFRY |
| Overall Dimension(L x W x H): | 8200x2500x2947mm | |
| Curb Weight: | 5500Kg | |
| GVW: | 18000Kg | |
| Wheelbase: | 4500mm | |
| Drive Type: | 4×2 | |
| Engine | Engine Model: | 6HK1-TCL |
| Engine Power: | 177Kw | |
| Delivery Capacity: | 7790ml | |
| Horsepower | 241PS | |
| Emission standard | Euro5 | |
| Transmission | Transmission: | Qingling MLD-6Q |
| Forward Gear: | 6Speed Gear | |
| Backward Gear: | 1 speed Gear | |
| Seats | Front Seat: | 3 |
| Chassis | Front Wheel Distance; | 1960mm |
| Rear Wheel Distance: | 1855mm | |
| Axle Loads: | Double Axles | |
| Tires: | 7 | |
| Tire Model: | 11.00R20 | |
| Configuration: | Power Seering. AC, Reflective Marking, ABS, Free Maintenance Batter, Data Recorder | |
| Body specs | Garbage Container Effective Capacity | 12 cubic |
| Filler Volume | 1.5 cubic | |
| Sewage tank | Equipped | |
| Working time of filling one time(S) | s16 | |
| Working; Time of unloading garbage(S) | S45 | |
| Rated pressure of hydraulic system(Mpa) | 20.6 | |
| PTO operation method | Electronic control valve Manual | |
| Manipulator | Standard dual manipulator 240L | |
