| Parameter | Specification |
| Welding Method | Submerged arc welding, gas shielded welding, or argon arc welding (customizable based on user requirements) |
| Welding Length | 1000–13000 mm (manufactured based on customer requirements) |
| Base Metal | Carbon steel, stainless steel, and aluminum alloy |
| Base Metal Thickness | 0.5–12 mm |
| Air Pressure | 0.4–0.6 MPa |
| Workpiece Clamping Method | Pneumatic piano-key clamping |
| Speed Regulation | Stepless speed regulation |
| Welding Speed | 50–800 mm/min |
| Welding Result | Single-sided welding with double-sided formation |
Hydraulic Pressure Vane Machine
The equipment can be used with an automatic plate tailor welding machine as a complete set to overturn tailored steel plates. The machine not only overturns the steel plate but can also be used as a shelf to hold the plate. Automatically overturning steel plates with the hydraulic turnover machine is fast and safe. After being overturned, chains automatically send the tailored plate to the bending machine for rolling, making the work more convenient.
The equipment is controlled by hydraulic pressure with high operability. Operation is simple and easy. The two sides of the machine clamp the workpiece tightly and overturn it 180°. The equipment consists of an overturning rack, overturning saddle, hydraulic pressure system, oil cylinder, chain conveyor, feed blocking device, and electrical control system.
