| Item | Specification |
|---|---|
| Workpiece swing diameter | 800–3500 mm (according to customer requirements) |
| Flip weight capacity | 1.5 T / 2.5 T / 5 T / 10 T / 13 T |
| Flip workpiece length | 4000–17,500 mm |
| Flip speed | 3900 mm/min |
| Flip angle | 0–360° |
| Drive mode | Electric |
Chain Variable-Bit Machine
It is suitable for turnover (flipping) of large and irregular structures, such as trailer frames, dump truck floors, dump truck boxes, subframes, tanks, etc.
The equipment uses a conical brake motor with high braking performance.
A PLC programmable control system is adopted to control all operating actions, ensuring the equipment is simple in structure, safe, and easy to operate.
The system mainly consists of a column-type chain turnover machine, conical brake motor combined with a cycloidal reducer, chain transmission, and a control system.
